Service Tools Operating & Maintenance Manual

113

DT-RT1

Crimp Tool for Deutsh pins

Crimp Available from: Ladd

Industries (800-223-1236)

54729710 Electrical Contact Cleaner

54729728 PDA Service Tool

54699616

Deutsch Terminal Removal

Tool

22073886 Packard Crimp Tool

22073878 Thermistor Simulator
