Operating & Maintenance Manual Service Tools

112

Service Tools

Tool No Tool Description Tool Illustration

Fluke 87

Digital multimeterAvailable

from electrical and electronic

parts distributors

54729660

Weather-Pack Terminal

Removal Tool

54699632

Deutsch Terminal Removal

Tool (Blue)

54699640

Deutsch Terminal Removal

Tool (Red)

54699624

Deutsch Terminal Removal

Tool (Yellow)
