Doosan HP375WJD-T3 - Compressor Specifications

Operating & Maintenance Manual General Arrangement
36
Compressor
COMPRESSOR
Actual free air delivery (7/120) (P425WJD)
12, 0 m
3
min
-1
(425 CFM)
Actual free air delivery (9/110) (XP375WJD)
10, 5 m
3
min
-1
(375 CFM)
Actual free air delivery (10/110) (HP375WJD)
10, 5m
3
min
-1
(375 CFM)
Normal operating discharge pressure (7/120) (P425WJD) 7 bar (100 PSI)
Normal operating discharge pressure (9/110) (XP375WJD) 8, 6 bar (125 PSI)
Normal operating discharge pressure (10/110) (HP375WJD) 10, 3 bar (150 PSI)
Maximum allowable pressure (7/120) (P425WJD) 8,6 bar (125 PSI)
Maximum allowable pressure (9/110) (XP375WJD) 10.3 bar (150 PSI)
Maximum allowable pressure (10/110) (HP375WJD) 12.1 bar (175 PSI)
Safety valve setting (7/120) (P425WJD) 10 bar (150 PSI)
Safety valve setting (9/110) (XP375WJD) 10 bar (200 PSI)
Safety valve setting (10/110) (HP375WJD) 14 bar (200 PSI)
Maximum pressure ratio (absolute) (7/120) (P425WJD) 7, 9: 1
Maximum pressure ratio (absolute) (9/110) (XP375WJD) 9, 6: 1
Maximum pressure ratio (absolute) (10/110) (HP375WJD) 11, 3: 1
