General Arrangement Operating & Maintenance Manual
37
Operating ambient temperature. Whisperized -12°C TO +49°C(10°F TO 120°F)
Maximum discharge temperature 120°C (248°F)
Cooling system Oil injection
Oil capacity 36 litres (9.5 GAL)
Maximum oil system temperature 120°C (248°F)
Maximum oil system pressure (7/120) (P425WJD) 8,6 bar (125 PSI)
Maximum oil system pressure (9/110) (XP375WJD) 10.3 bar (150 PSI)
Maximum oil system pressure (10/110) (HP375WJD) 12.1 bar (175 PSI)
