022-00029AE Operation and Maintenance Manual Inspection, Maintenance and Adjustment 4-31
REPLACE DCA4 COOLANT FILTER CARTRIDGE
1. Park the machine on a level surface, apply
the parking brake, lower the attachment to
the ground, and stop the engine.
2. Press the button on the radiator tank cap to
release any remaining pressure, and remove
the cap slowly (Figure 56).
3. Turn the coolant shutoff valve "OFF."
CAUTION!
Pressurized radiator tank.
Spray of hot coolant can cause burn.
Stop engine and allow radiator and coolant to cool completely, then open cap slowly to relieve
pressure.
CAUTION!
Hot coolant and engine components can cause burn.
Avoid contact with coolant or engine components.
Figure 56
Figure 57
