Harness Connector Information
The following is a complete list of the connectors and connector parts that are used on the
machine harnesses. The most common replacement connectors and connector parts will be
found in the Deutsch terminal repair kit, Packard terminal repair kit, and WJDe terminal repair kit.
A repair kit is available for the WEDGE connector and Engine ECM connector. Check the
Electrical Parts List section for individual replacement harness parts for certain items. If the
connectors and connector parts are not in the kits above, the manufacturer part numbers and
contact information will be provided.
Connector and Parts Manufacturer
Manufacturer’s Part
No.
Included in
Doosan Service
Kit Part No.
P1 WEDGE Connector
Plug, 40 way Deutsch DRC16-40S 22252993
Socket size 16 Tin Deutsch 0462-201-16141 22252993 /
46490983
Socket size 14 Tin Deutsch 0462-209-16141 22252993 /
46490983
Socket size 16 Gold Deutsch 0462-201-1631 22252993 /
46490983
Sealing plug size 16-12 Deutsch 114017 22252993 /
46490983
Rubber Boot Deutsch DRC40-BT
P4 Control Panel Connector
Plug, 12 way Deutsch DT06-12SA-EP08
Rubber Boot Deutsch DT12S-BT-BK
Socket size 16 Tin Deutsch 0462-201-16141 46490983
Socket size 14 Tin Deutsch 0462-209-16141 46490983
Sealing plug size 16-12 Deutsch 114017 46490983
J4 Control Panel Connector
Receptacle, 12 way Deutsch DT04-12PA-E005
Rubber Boot Deutsch DT12P-BT-BK
Pin size 16 Tin Deutsch 0460-202-16141 46490983
Pin size 14 Tin Deutsch 0460-215-16141 46490983
Sealing plug size 16-12 Deutsch 114017 46490983
P10 Accessory Connector
Plug, 6 way Deutsch DT06-6S-EP06 46490983
Wedgelock Deutsch W6S-P012 46490983
Socket size 16 Gold Deutsch 0462-201-1631 46490983
J10-Cap Accessory Connector
Receptacle, 6 way Deutsch DT04-6P-E005 46490983
Sealing plug size 16-12 Deutsch 114017 46490983
RT1, RT2 Temperature Sensor Connector
Plug, 2 way Packard 15300027 46491296
TPA Packard 15300014 46491296
Terminal, 18-16 Awg Packard 12077411 46491296
Cable Seal Packard 12089679 46491296
PT1, PT2 Pressure Sensor Connector
Plug, 3 way Packard 13532244 46491296
TPA Packard 15452678 46491296
