Book: 23227143 (8-24-2010) Rev CPage96
Connector and Parts Manufacturer
Manufacturer’s Part
No.
Included in
Doosan Service
Kit Part No.
Cable Seal Packard 15305351 46491296
J5 WEDGE Controller Communication Connector
Receptacle, 9 way Deutsch HD10-9-96P 46490983
Connector Cap Deutsch HDC9-JDL082397 46490983
Pin size 16 Gold Deutsch 0460-202-1631 46490983
Sealing plug size 16-12 Deutsch 114017 46490983
P7, P8, P12 Options Connectors
Plug, 2 way Deutsch DT06-2S-EP06 46490983
Wedgelock Deutsch W2S-P012 46490983
Socket size 16 Tin Deutsch 0462-201-16141 46490983
J7-Cap, J8-Cap, J12-Cap Options Connector
Receptacle, 2 way Deutsch DT04-2P-E005 46490983
Sealing plug size 16-12 Deutsch 114017 46490983
P2, P3 J1939 CAN Terminator Connector
Plug, 3 way Deutsch DT06-3S-EP06 46490983
Wedgelock Deutsch W3S-1939-P012 46490983
Socket size 16 Gold Deutsch 0462-201-1631 46490983
TR1, TR2 J1939 CAN Terminators
Receptacle, 3 way
terminator
Deutsch DT04-3P-EP10 46490983
C11 Engine Service Connector
Receptacle, 9 way Deutsch HD10-9-1939PE
Connector Cap Deutsch HDC9-JDL082397 46490983
Pin size 16 Gold Deutsch 0460-202-1631 46490983
Sealing plug size 16-12 Deutsch 114017 46490983
S1 Ignition Switch Connector
Plug, 4 way Packard 12052856 46491296
TPA Packard 15324456 46491296
Terminal 18-16 Awg Packard 12034046 46491296
Terminal, 16-14 Awg Packard 12066214 46491296
U1 Low Fuel Shutdown/Gauge Sender Connector
Plug, 4 way Packard 12015797 46491296
Terminal, 20-18 Awg Packard 12089188 46491296
Cable Seal Packard 12089679 46491296
F1, F2, F3 Fuse Connector
Plug, 2 way Fuse Packard 12085030 46491296
Fuse Connector Cap Packard 12033731 46491296
Terminal, 16-14 Awg Packard 12033997 46491296
C07 Auxiliary Power Connector
Plug, 3 way Packard 12040977
TPA Packard 12034145
Terminal, 12-14 Awg Packard 12129493
Terminal, 18-16 Awg Packard 12077411 46491296
Cable Seal 12 Awg Packard 12015193
Cable Seal 16 Awg Packard 12089679 46491296
C18 Connector To C03 on Engine
Plug, 3 way Packard 12110293
TPA Packard 12052845
To Next Page
