Dorma ED 100 Mounting Instructions

DORMA
DORMA
DORMA
11
45
45
150
10695
245
B
D
C
120 100120120
50
32
63
A
33
Ø 6,6
ED 100/250
Bottomedgeoflintel
Bottomedgeoflintel
ED100=0mm-300mm
ED250=0mm-500mm
Cableinsert
7. Mounting on opposite hinge side
Axle extension ED 100 ED 250 A B C D
Standard(9mm)
19mm 51mm 9mm 42mm
30mm
49mm 81mm 39mm 72mm
60mm
79mm 111mm 69mm 102mm
90mm ---
109mm 141mm 99mm 132mm

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
