Dorma ED 100 Mounting Instructions

DORMA
DORMA
DORMA
9
45
150
106
45
120 120 95
451
155
B
D
A
C
120100
32
19
63
Ø 6,6
ED 100/250
Upperedgeofdoor
Upperedgeofdoor
Maximumlinteldepth±30mm
Cableinsert
Door without rebate
5. Mounting on hinge side with 12.5 mm pivot pin
Axle extension ED 100 ED 250 A B C D
Standard(9mm)
31mm 50mm 22mm 41mm
30mm
61mm 80mm 52mm 71mm
60mm
91mm 110mm 82mm 101mm
90mm ---
121mm 140mm 112mm 131mm

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
