Dorma ED 100 Mounting Instructions

DORMA
DORMA
6
DORMA
ED 100/250
ED 250
Max.powerconsumption 240Watts
Closingforce EN4–6continuously
adjustable
Max.door-leafweightfor
linteldepthsofupto300mm
250kgfordoor-leafwidths
ofupto1,400mm
190kgfordoor-leafwidths
ofupto1,600mm
Max.door-leafweightforlintel
depthsfrom301to500mm
160kg
Door-leafwidth 700–1,600mm
Door-leafwidthfor
fireprotectiondoors
700–1,400mm
Max.openingspeed **60°(27°*)/second
Max.closingspeed **60°(27°*)/second
Axleextension 30/60/90mm
Linteldepthforslidechannel +/-30mm
Linteldepthforstandardarm 0–500mm
ED 100
Max.powerconsumption 120Watts
ClosingforceEN1154 EN2–4continuously
adjustable
Max.door-leafweightfor
linteldepthsofupto300mm
100kg
Door-leafwidth 700–1,100mm
Max.openingspeed **50°(27°*)/second
Max.closingspeed **50°(27°*)/second
Axleextension 30/60mm
Linteldepthforslidechannel +/-30mm
Linteldepthforstandardarm 0–300mm
* Thevaluesinbracketsindicatethemaximumspeed
inLow-EnergyModewithoutFull-EnergyorFire
ProtectionUpgradeCards.
** Dependingonthedoor-leafweightautomatically
limitedaccordingtoDIN18650,BS7036-4and
ANSI156.19.
Torque overview
ED 100
Wayofmounting Lintelmountingonhingeside
withslidechannel,pull-version
Lintelmountingonoppositehinge
sidewithstandardarm,push-version
minimum maximum minimum maximum
ClosersizeEN1154 EN2 EN4 EN2 EN4
Closingtorque(manually)[Nm] 13 34 13 37
Closingtorque(Automatic)[Nm]** 20 FE:150/LE:67 20 FE:150/LE:67
Openingtorque(manually)[Nm] 30 50 35 55
Openingtorque(Automatic)[Nm]** 20 FE:150/LE:67 20 FE:150/LE:67
Openingtorqueofmanually-activated
Power-AssistFunction(Nm)*
23 23 23 23
ED 250
Wayofmounting Lintelmountingonhingeside
withslidechannel,pull-version
Lintelmountingonoppositehinge
sidewithstandardarm,push-version
minimum maximum minimum maximum
ClosersizeEN1154 EN4 EN6 EN4 EN6
Closingtorque(manually)[Nm] 26 65 26 70
Closingtorque(Automatic)[Nm]** 20 FE:150/LE:67 20 FE:150/LE:67
Openingtorque(manually)[Nm] 55 85 60 90
Openingtorque(Automatic)[Nm]** 20 FE:150/LE:67 20 FE:150/LE:67
Openingtorqueofmanually-activated
Power-AssistFunction(Nm)*
23 23 23 23
FE WithFull-EnergyorFireProtectionUpgradeCardFull-Energy,
LE Low-EnergybasicoperatorwithoutUpgradeCard
* Power-Assistadjustedtomaximum,effectivefromanopeningwidthofapprox.3°.
** ThetorqueisactivatedbyanautomaticopeninginAUTOMATICmode.
Power-Assist Function
ThePower-AssistFunctionmaybeactivatedwhilethedoor
isindoorclosermode(parameterHd=1).Assoonasauser
opensthedoormanuallybysomedegrees,theservo-function
supportsthemanualopeningcycle.Theservosupport
automaticallyadaptstotheadjustedsizeofthedoorcloser.
Thelevelofservosupportisadjustableinordertomeet
therequirementsofDIN18040,DINSpec1104,CEN/TR
15894,BS8300/2100anddocument"M",evenuptoclass
EN6
Thesmallestadjustableopeningtorqueamountsto23Nm/5
lbf.,unlessthehold-opendeviceistriggeredorintheevent
ofapowerfailure.WiththeaidofthePower-AssistFunction,
thesystemmeetstherequirementsoftheEuropeanstandard
EN1154andprovidesbarrier-freeaccessduringstandard
operation.
However,itisnotpossibletousethesysteminconjunction
withthePush&GoFunctionorthewindloadcontrolas
thesefunctionsmayaffecttheeasymanualopening.

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
