Dorma ED 100 Mounting And Commissioning Instructions

45
32
45
150
106 120 120 95
451
155
B
D
A
C
120100
32
63
Lintel depth maximum ± 30 mm
Ø 6.6
Upper edge door
Upper edge door
Space for cable feed
Door with rabbet
Assembly on the hinge side pull version with slide channel and 25 mm lever pin
Axis extension ED 100 ED 250 A B C D
Standard (9 mm) 31 mm 63 mm 22 mm 54 mm
20 mm 51 mm 83 mm 42 mm 74 mm
30 mm 61 mm 93 mm 52 mm 84 mm
60 mm 91 mm 123 mm 82 mm 114 mm
90 mm --- 121 mm 153 mm 112 mm 144 mm
ED 100, ED 250
—
11

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
