ED 250
Max. power input 240 Watt
Closing torque EN 4 – 6 infinitely variable
Max. door panel weight
up to a lintel depth of 300 mm
400 kg, depending on the
door panel width
Max. door panel width
301 – 500 mm lintel depth
160 kg
Door panel width 700 – 1,600 mm
Door panel width fire
protection
700 – 1,400 mm
Opening speed 0 – 90° 3* – 12 seconds
Closing speed 90 – 0° 4* – 21 seconds
Axis extension 20/30/60/90 mm
Lintel depth slide channel
(CPD)
+/- 30 mm (- 60 mm)
Lintel depth standard arm
assembly
0 – 500 mm
ED 100
Max. power input 120 Watt
Closing torque EN 1154 EN 2 – 4 infinitely variable
Max. door panel weight
up to a lintel depth of 300 mm
160 kg, depending on the
door panel width
Door panel width 700 – 1,100 mm
Opening speed 0 – 90° 4* – 12 seconds
Closing speed 90 – 0° 5* – 21 seconds
Axis extension 20/30/60 mm
Lintel depth slide channel
(CPD)
+/- 30 mm (- 60 mm)
Lintel depth standard arm
assembly
0 – 300 mm
* Depending on the door leaf weight automatically limited
according to EN 16005 or DIN 18650, BS 7036-4 and
ANSI 156.19 with operating mode low-engergy.
Max. speeds will only be reached in operatiang mode
full-energy, a low door leaf weight and a learned opening
angle of min. 95°
3.8 Torque overview
ED 100
Installation type Lintel mounting on hinge side,
pull version of slide channel
Lintel mounting on opposite hinge side,
push version of standard arm/
push version of slide channel
minimum maximum minimum maximum
Closer size pursuant to EN 1154 EN 2 EN 4 EN 2 EN 4
Manual closing torque (Nm)*** 13 34 13 37
Automatic closing torque (Nm)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Manual opening torque (Nm) 30 50 35 55
Automatic opening torque (Nm)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Opening torque of manually activated
power-assist function (Nm) *
23 23 23 23
ED 250
Installation type Lintel mounting on hinge side,
pull version of slide channel
Lintel mounting on opposite hinge side,
push version of standard arm/
push version of slide channel
minimum maximum minimum maximum
Closer size pursuant to EN 1154 EN 4 EN 6 EN 4 EN 6
Manual closing torque (Nm)*** 26 65 26 70
Automatic closing torque (Nm)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Manual opening torque (Nm) 55 85 60 90
Automatic opening torque (Nm)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Opening torque of manually activated
power-assist function (Nm) *
23 23 23 23
FE With installed Full-Energy or Fire Protection Upgrade Card
LE Low-energy basic device without Upgrade Card
* If power-assist support set to maximum, effective from an opening width of approx. 3°.
** The torque is available in the event of automatic opening in automatic mode.
*** In the push version of the slide channel installation type, the forces reduce by approx. 33%.
ED 100, ED 250
—
8

Dorma ED 100 Specifications

General

Adjustable Closing Speed	Yes
Latching Speed	Adjustable
Type	Electromechanical
Power Supply	230 V AC, 50 Hz
Fire Rated	Yes
Backcheck	Adjustable
Delayed Action	Adjustable
Hold-Open Function	Yes
Finish	Silver
