DORMA AUTOMATICES, Inc. 924 Sherwood Drive Toll-Free: 877-367-6211 Subject to change without notice
DL3463-050 08/2016 Lake Bluff, IL 60044 Fax: 847-249-3999
ED100 / ED250 SERVICE MANUAL
—
4
14
11
4
8
9
10
6
7
6
54
3
2
1
12
13
Operator
1. AC power switch
2. AC power connection
3. Connection board terminals
4. Axle connection on both sides
5. Drive system (motor/gear/spring)
6. Spring tension adjustment – closing force
7. Slot for DORMA upgrade cards
8. Internal program switches (2)
9. User interface with information display
10. Potentiometer, closing speed adjustment
11. Terminal jumper, push or pull mounting
Standard arm, Track (slide channel), complete cover
12. Standard arm
13. Track and arm
14. Complete cover
2 Operator system
