Parameter detail
Parameters / Display Value range
Unit
factory setting
= bold
Explanation
1. Installation type 0 – 2 0 ■ Frame or wall-mounting on swing (hinge) side with track (slide
channel), pull version (v1.9).
■ Standard track can be used up to a reveal depth of
+ 1 3/16" [30 mm].
■ By use of track with CPD (centrally pivoted door), range of
reveal depth increases to + 2 3/8" [60 mm] (v1.9).
Entered value of rd must then be reduced by 30.
■ Example: ED250 with track CPD in pull installation with a reveal
depth of 2" [50 mm]. Parameter rd setting: 20.
1 Frame or wall mounting on approach (opposite hinge) side with
standard arm, push version.
2 Frame or wall-mounting on approach (opposite hinge) side with
track, push version – on door(s) without smoke/fire protection
requirements (v1.9).
■ Use of track with CPD in push installation is not possible.
■ Axle extension must be installed in this application and rotated
45º.
■ Maximum reveal depth is +2 3/8" [60 mm].
■ Maximum door opening width with a reveal depth of + 2 3/8"
[60 mm] is reduced to 95º.
2. Reveal depth ED 100
3 – 30
1 3/16" to
11 13/16"
30 - 300 mm
ED 250
3 – 50
1 3/16" to
19 11/16"
30 - 500 mm
0
■ Reveal depth is set in increments of 10 mm (3/8").
■ Refer to installation instructions – Measure and record reveal
depths – for values.
■ If using CPD lever (see parameter AS), approximately 3/16"
[30 mm] must be deducted from actual reveal depth.
3. Door width ED 100
7 – 11
28" - 40"
700 - 1100 mm
ED 250
7 – 16
28" - 64"
700 - 1600 mm
10
■ Parameter is "Tb".
■ Door width is specified in increments of 4" [100 mm].
■ Rebate is included in the door width.
■ See Installation instructions,
First commissioning, door width parameter Tb, for chart..
4. Door type 0 – 4 0 ■ Single door.
1 ■ Double door, with overlapping door (with astragal):
active door operator. Door opens first.
2 ■ Double door, with overlapping door (with astragal):
passive door operator.
3 ■ Double door, with edgeless door (no astragal):
active door operator. Both doors open simultaneously.
4 ■ Double door, with edgeless door(no astragal):
passive door operator. Both doors open simultaneously.
