79/RT/E7900/770/E-760/660 Series PK3678_T 04-18 13
3 Installation of Standard ASM or ESM Models
3.5 Reversing the Outside Lever
(for Series without Mechanical Override)
The lever is field reversible. If the handing is incorrect, in-
sert a small pick or flat screwdriver in the hole in the hub as
shown. Gently pry back the spring clip inside the hub, and
remove the handle.
Access Hole
cut-away view
3.6 For Cylindrical, see p.33
IMPORTANT
If the lock makes a continuous buzzing noise or the red LED
lights continuously, reset the electronics by removing the
battery holder for ten seconds then reinsert it.
E1
