4 79/RT/E7900/770/E-760/660 Series PK3678_T 04-18
2.1 Parts and Tools List
Each lockset includes:
(A) Outside lever handle
(or)
Parts for mechanical override model only:
(A1) Outside lever handle
(A2) Cylinder plug
(A3) Cylinder (locks with key cylinder)
(A4) Cylinder cap (locks with key cylinder)
(B) Outside housing
(C) Battery holder with 3 AA batteries & Screw
(C1) Battery holder with 3 AA batteries
(C2) Torx-head screw (E-760/770/790/79M/RT)) (see
hardware bag)
(D) Mortise (ASM only shipped assembled with faceplate
and 2 x 8-32 x 1/4" screws)
(or)
Parts for cylindrical models (see illustrations in
appendix B):
- cylindrical latch (see B2 page 33)
- cylindrical unit assembled with one pair of screws &
3 spacers
- four (4) other pairs of screws & 3 spacers in
hardware bag
- additional extension spring
- storeroom function locking screw and nut
(E1) Inside trim no Messenger and no bluetooth
(E2) Inside trim with Messenger and or bluetooth
(E3) Inside trim E-7900(N)
Parts inside hardware bag:
(F1) Spindle regular
(F2) Spindle E7900
(G) Square spindle
(C2) Torx-head screw (E-760/770/790/79M/RT))
(I) 3 x mounting screws (10-24, 1/8 Hex Head) or (12-24,
1/8" Hex Head for recent models only)
(J) 2 Machined screws (12-24X 1/2" Philips) & 2 wood
screws (#12 X 1" Philips)
(K) Strike kit (screws, strike and ASM or Cylindrical
dustbox)
(L) 1 extension spring
(M) Parts required to control thumbturn motion (ASM
and ESM Storeroom, ASM Office) See appendix A3 &
A4
(Q1) 4 pairs of Flat Head Screws 10-24 (for cylindrical only)
(R1) 3 Spacers (for cylindrical only)
(R2) 1 Cylinder with 2 keys for 660/660i Series with
override and cylinders keyed different only
(S) 3 spacers (see page 31) for recent Models only
(V) 2 x battery cover screws (4-40, 1/2 Torx Head) (For
E7900 only)
(W) 1 Torx key (T10) (for E7900 only)
Tools Required:
• Safety glasses
• 1/2" (13mm) chisel
• 1/8" (3mm) drill bit
• 1/4" (6.5mm) drill bit (ESM only)
• 1/2" (13mm) drill bit
• 3/4" (19mm) drill bit
• 1" drill bit or hole saw
• 3/32" drill bit (Cylindrical only)
• 1/8" Hexagonal key (Allen key)
• Drill
• Awl or center punch
• 2 1/8" (54mm) hole saw (Cylindrical Only)
• Hammer Rubber mallet
• Small flat screwdriver
• Torx screwdriver (T-15)
• Phillips screwdriver (#2)
• Fine steel file
• Mortising machine
• Router
• Mortise faceplate router template
• Adjustable square
• Tape measure
• Pencil
• Tape
• Cleaning supplies (drop cloth, vacuum)
• Spanner screwdriver #6 (660/660i Series)
IMPORTANT
For doors more than 2 1/2" thick upto 3 3/4", order the ap-
propriate hardware bag to receive the correct length of
spindles and mounting screws. Part# 062-510189-XXX; (XXX
= choice of finish).
For outdoor installations, order gasket 033-510181-1 for
E-760 Series. For 770/79 Series/RT Series order Gasket 033-
512017-1. Gasket comes standard with 660/E-760/770/79
Series/RT cylindrical and E-760/770/79 series/RT supreme
finish locks.
Outdoor gasket included in all 660 series, all locks with cylin-
drical latch and for locks with supreme finish.
Order separately for other locks with mortise. ESSENTIAL
FOR OUTDOOR INSTALLATIONS
2 Checklist and Exploded Views
