Dormakaba ED 100 Mounting Instructions

Assembly on the hinge side pull version with slide channel and long lever bolt
45
32
150
106 120 120 95
451
155
A
C
120100
32
B
D
63
45
Lintel depth maximum ± 30 mm
Ø 6,6
Upper edge door
Space for cable feed
Door with rabbet
Axis extension ED 100 ED 250 A B C D
Standard ● ● 31 mm 63 mm 22 mm 54 mm
20 mm ● ● 51 mm 83 mm 42 mm 74 mm
30 mm ● ● 61 mm 93 mm 52 mm 84 mm
60 mm ● ● 91 mm 123 mm 82 mm 114 mm
90 mm --- ● 121 mm 153 mm 112 mm 144 mm
Upper edge door
12
dormakaba Preparing for installation
ED 100, ED 250
Mounting instructions
WN 059799 45532
2019-07
