Dormakaba ED 100 Mounting Instructions

4 Preparing for installation
1. Use the following data to check whether the
device meets the necessary requirements. You can
get started with the installation process if the
parameters have been complied with.
ED 100 ED 250
EN 3 – 4 EN 4 – 6 EN 7
Standard arm 225
29271xxx
F/225 F/225 F/125
Standard arm 500
29272xxx
F/300 F/500 o
Pull version of slide
29275xxx
F/30 F/30 o
Push version of
29275xxx
o F/EN4/30 o
Pull version of slide
channel CPD 29276xxx
F/60 F/60 o
Push version of
channel CPD 29276xxx
o o o
Axle extension
20 mm
29278012
F F F
30 mm
29278013
F F F
60 mm
29278016
F F F
90 mm
29278019
x F/350 o
F Suitable for use on standard,
fire and smoke doors.
F/xxx Suitable for use on standard, fire and smoke
doors; the lintel depth is limited to xxx mm.
F/EN4/xxx Suitable for use on standard, fire and smoke
doors; limited to EN 4, the lintel depth is limited to
xxx mm.
o Suitable for use on standard doors.
x Combination not possible
2. Depending on the installation situation, select the
corresponding drilling pattern on pages 11 – 18.
3. Drill the holes shown in the drilling pattern in the
door leaf and frame/wall.
10
dormakaba Preparing for installation
ED 100, ED 250
Mounting instructions
WN 059799 45532
2019-07
