3.8 Torque overview
ED 100
Installation type
Lintel mounting on hinge side,
pull version of slide channel
Lintel mounting on opposite
hinge side, push version of
standard arm/
push version of slide channel
minimum maximum minimum maximum
Closer size pursuant to EN 1154 EN 2 EN 4 EN 2 EN 4
Manual closing torque (Nm)*** 13 37 13 37
Automatic closing force (N)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Manual opening torque (Nm) 30 50 35 55
Automatic opening force (N)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Opening force of manually activated
power-assist function (N) *
23 23 23 23
ED 250
Installation type
Lintel mounting on hinge side,
pull version of slide channel
Lintel mounting on opposite
hinge side,
push version of standard arm/
push version of slide channel
minimum maximum minimum maximum
Closer size pursuant to EN 1154 EN 4 EN 6 EN 4 EN 6
Manual closing torque (Nm)*** 26 65 26 90
Automatic closing force (N)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Manual opening torque (Nm) 55 85 60 90
Automatic opening force (N)** 20 FE: 150/LE: 67 20 FE: 150/LE: 67
Opening force of manually activated
power-assist function (N) *
23 23 23 23
FE With installed Full-Energy or Fire Protection Upgrade Card
LE Low-energy basic device without Upgrade Card
* If power-assist support set to maximum, effective from an opening width of approx. 3°.
** The torque is available in the event of automatic opening in automatic mode.
*** In the push version of the slide channel installation type, the forces reduce by approx. 33%.
9
dormakaba Product description
ED 100, ED 250
Mounting instructions
WN 059799 45532 2019-07
