Dormakaba ED 100 Mounting Instructions

Integrated functions
Latching action Force is adjustable
Hold-open time in case of
automatic opening
0 – 30 seconds
(Optional 0 – 180
seconds)
Hold-open time
night/bank
0 – 30 seconds
Hold-open time in case
of manual opening
0 – 30 seconds
Blocking behavior
Reversing/
door closing function
Unlocking time door
opener
0 – 4 seconds
Locking response Motor lock
Wind load control Up to 150 N
Voltage independent
braking circuit
Adjustable with
potentiometer
LED status display
green
red
yellow
- Operating control
voltage
- Error message
- Service interval
display
Integrated program
switch
Off
Automatic
Permanent open
Exit only (only for
1-panel systems)
User interface with
information display
Status display and
parameterization
Slot for
Upgrade Cards
Extension of the
functional range
Update interface Update firmware
TMP – Temperature
Management Program
Overload protection
IDC – Initial-Drive-
Control
Driving cycle
optimization
Cycle counter
0 – 1,000,000
(meaningful division)
Power assist function
Servo assist in case of
a manual opening
Push & Go function
Door opening in
case of a manual
movement of 4°
ED 250
Max. power input 240 Watt
Closing torque
EN 4–6 infinitely
variable
Max. door panel weight
up to a lintel depth of
300 mm
400 kg, depending on
the
door panel width
Max. door panel width
301 – 500 mm lintel
depth
160 kg
Door panel width 700 – 1,600 mm
Door panel width fire
protection
700 – 1,400 mm
Opening speed 0 – 90° 3* – 12 seconds
Closing speed 90 – 0° 4* – 21 seconds
Axis extension 20/30/60/90 mm
Lintel depth slide channel
(CPD)
+/- 30 mm (- 60 mm)
Lintel depth standard
arm assembly
0–500 mm
ED 100
Max. power input 120 Watt
Closing torque EN 1154
EN 2–4 infinitely
variable
Max. door panel weight
up to a lintel depth of
300 mm
160 kg, depending on
door panel width
Door panel width 700–1,100 mm
Opening speed 0 – 90° 4* – 12 seconds
Closing speed 90 – 0° 5* – 21 seconds
Axis extension 20/30/60 mm
Lintel depth slide channel
(CPD)
+/- 30 mm (- 60 mm)
Lintel depth standard
arm assembly
0–300 mm
* Depending on the door leaf weight
automatically limited according to EN 16005
or DIN 18650, BS 7036-4 and ANSI 156.19 with
operating mode low-engergy. Max. speeds will
only be reached in operatiang mode full-energy, a
low door leaf weight and a learned opening angle
of min. 95°.
8
dormakaba Product description
ED 100, ED 250
Mounting instructions
WN 059799 45532
2019-07
