3.6.2 Locking device
In general, the following types of devices are locking
devices: electrical door opener (E-opener), motor
locks, multi-point locking device with response
contact, holding magnets.
Motor locks without a locking response can be directly
connected to the drive unit if the locking time is less
than 4 seconds. In order to ensure the safe operation
of the combined drive unit and locking device, the
locking device must meet the following specifications.
Minimum requirements:
Operating voltage when supplied by the drive unit:
24 V DC +/- 5 %
Operating voltage with an external supply:
max. 48 V DC/AC
Load of the contact relay locking:
max. 1 A
Switch-on time electrical door opener:
min. 30 %
Switch-on time motor lock:
100 %
3.6.3 Key switch button ST 32 DCW
Key left
> 3s:
A connected DCW program switch
switches to off and the red LED is
on.
Key right
< 3s:
Night/bank pulse
Key right
> 3s:
A connected DCW program switch
switches to automatic and the
green LED is on.
3.6.4 I/O-module DCW
Adress: 00 (DIP switch position)
In 1 – In 4 are without function
Functions for Out 1 to Out 4
(adjustable via hand terminal)
0 No Function
1 Door is closed
2 Door is open
3 Error
4 Door closed and locked
5 Information or error
6 Larger than door angle x°
Factory setting:
Out 1 4 Out 2 2 Out 3 5 Out 4 6
3.7 Technical data
Application conditions
Ambient temperature - 15 to + 50 °C
Only for dry rooms
Relative air humidity
max. 93 %
non-condensing
Power supply
230 V AC +10 %/-15 %,
50 Hz
Protection class IP 20
General
Dimensions (WxHxD) 685 x 70 x 130 mm
Min. clearance between
hinges 2-panel
1,400 mm
Min. clearance between
hinges 2-panel with ESR
1,450 mm
Min. clearance between
hinges 2-panel with VARIO
casing
1,500 mm
Drive unit weight 12 kg
Power supply for external
consumers
24 V DC +/- 5 %, 1,5 A
Door opening angle Max. 95° – 110°
depending on the type
of installation
Fuse protection provided by
the customer
16 A
Operating noise Max. 50 dB(A)
Inputs
Connecting terminals Max. 1.5 mm
2
Potential-free activator Internal and external
(NO contact)
Night/bank
(intercom)
8 – 24 V DC/AC + 5 %
Night/bank (key switch) Make contact/
NO/NC contact
Safety sensor BS and BGS (NC
contact)
Test signal safety sensor BS and BGS
Shutdown drive function
(door lock switch)
NC contact/
NO contact
Outputs
Connecting terminals max. 1,5 mm
2
Potential-free status
contact
Door closed
Door open
Error
Door closed and locked
7
