Dormakaba ED 100 Mounting Instructions

3.5 Upgrade-Cards
The Upgrade Cards allow you to extend the functional
range of the automatic swing door operator units
ED 100 and ED 250. During the installation of the
Upgrade Cards, information between the control unit
and the Upgrade Card is exchanged and assigned. The
desired function can be used as long as the Upgrade
Card is installed in the drive unit.
• The first installed Upgrade Card becomes the
container module. The functions of additional
Upgrade Cards are saved in the container module.
Each control unit features only one container
module.
• The status of the Upgrade Card is indicated by 3
integrated LEDs. The red LED lights in case of the
DCW Upgrade Card as soon as the DCW members
are logged on and it indicates that DCW telegrams
are being exchanged.
3.5.1 Combination options
There are several functions available. The Upgrade
Cards are colored in order to differentiate between
them.
Upgrade-Card Color ED 100 ED 250
Full-Energy blue X
Full-Energy
blue
transparent
X
Fire Protection red X
Fire Protection
red
transparent
X
Professional green X X
DCW yellow X X
Barrier-free WC black X X
3.5.2 Upgrade-Card Full-Energy –
blue/blue transparent
The Upgrade Card Full Energy allows you to make use
of the full setting range of the opening and closing
speed parameters as well as the opening and closing
torque. It can be used for 2-panel systems.
3.5.3 Upgrade-Card Fire Protection –
red/red transparent
The Upgrade Card Fire Protection is needed to set up
a hold-open system in accordance with EN 14637 or
similar standards. The line-monitored detector input
for the connection of the RM-ED or the integrated
smoke detector is only available with the installed
Upgrade Card Fire Protection. The Full Energy
function will be automatically activated. It can be
used for 2-panel systems.
3.5.4 Upgrade-Card Professionell – green
The use of the Upgrade Card Professional allows
you to activate the functions nurse bed, extended
hold-open time and impulse relay. It can be used for
2-panel systems.
3.5.5 Upgrade-Card DCW – yellow
The Upgrade Card DCW allows the connection of
DCW-compatible accessory components to the drive
unit. It can be used for 2-panel systems.
3.5.6 Upgrade-Card Barrier-free WC –
black
With the use of the Upgrade Card Barrier-free
WC, the inputs and outputs of the control unit are
assigned with the functions especially required for this
application. The required accessory components can
be directly connected. The Upgrade Card Barrier-free
WC is not used for 2-panel systems.
3.6 Accessories
In addition to an extensive range of accessories,
many activators, locking devices, safety sensors and
accessories of other manufacturers are available
and could be used together with the drive units ED
100 and ED 250. dormakaba cannot guarantee the
compatibility with devices from other manufacturers.
If those devices are always used, the full functional
range of the drive units may not be available or the
devices may not function properly. The drive unit or
the connected device may also become damaged.
The operator can provide a maximum 1.5 A with 24
V DC for external consumers. In case more current is
required (even if only temporarily), an external power
supply is to be used in order to prevent a malfunction
of the drive unit.
3.6.1 Activator
In general, the following types of devices are
activators: radar motion sensors, passive infrared
motion sensors, pushbuttons, switches, sensor
buttons, radio, IR-receivers, access control systems,
telephone and intercom systems.
Minimum requirements:
Operating voltage when supplied by the drive unit:
24 V DC +/- 5 %
Pulse duration:
min. 200 ms
Potential-free output:
(in case a signal input internal is used,
external detector or night/bank)
Energized output (telephone systems):
max. 24 V DC/AC +/- 5 %
6
dormakaba Product description
ED 100, ED 250
Mounting instructions
WN 059799 45532
2019-07
