14
ED250 01-2018DL4614-090
dormakaba ED250 IG Owner's Manual Chapter 8
ED in-ground door threshold
. Install door threshold
.. Door threshold seal at spindle.
CAUTION
Spindle opening at threshold must be sealed
with an O-ring or similar device.
.. Door threshold perimeter seal
CAUTION
Threshold perimeter must be sealed with a
silicone sealant.
.. Cleaning door threshold and floor area around
threshold.
Fig. 8.1.3 Threshold installation end view example
Fig. 8.1.1 Threshold example for ED250 in-ground
Fig. 8.1.2 Door threshold installation example for
ED250 in-ground
CAUTION
Do not pressure wash door threshold or floor
area adjacent to door threshold!
WARNING
Access to the ED in-ground system must
only be done by dormakaba USA Inc. certified
technicians!
NOTICE
Door threshold installation and maintenance is
owner's responsibility
Door threshold
Spindle
ED250 in-ground
cement case
To Next Page
