dormakaba ED250 IG Owner's Manual Chapter 3
What you should know
.. dormakaba USA Inc. distributor information.
Be sure that the dormakaba USA Inc. distributor has
provided the following information for each door
installation:
. dormakaba USA Inc. ED in-ground Owner's
Manual.
. Review of the daily Safety information checklist
(Chapter ).
. Instructions on how to conduct the daily Safety
Information checklist by walk through example.
. Annual compliance inspection label completion
(Chapter ).
. Circuit breaker or disconnect location for Vac
power to the ED in-ground system.
. ED program switch panel location and
instructions in its use. (Para. .).
. Discussion of problems that could result from
operator being allowed to operate after a
malfunction observed.
. Number to call for service or questions about your
system if you are uncertain of any condition or
situation.
WARNING
If there are any problems, discontinue door
operation immediately and secure the door in
a safe manner. Call your local dormakaba
USA Inc. distributor for repair.
Fig. 3.3.1 Program switch panel
.. Program switch door control modes.
. Auto, door opens when actuated by:
• Knowing act device (Para. .). Door will remain at
full open position for not less than seconds.
• Push/pull actuation of door, Para. ... Door will
remain at full open position for not less than
seconds.
. Auto, door opens automatically when one of the
activators is actuated or triggered and closes on
expiration of adjustable hold open time with no
activators or actuators triggered.
. Open, door opens automatically and remains open.
. Close, door will remain closed, or if door is open door
will close.
.. Exit only switch.
• Off, interior and exterior activation sensors both
active.
• On, exterior activation sensor disabled when door
fully closed. Only interior activation sensor will enable
door opening.
.. Exit only switch modes
• Off, Interior and exterior activation sensors both
active.
• On, exterior activation sensor disabled when door
fully closed. Only interior activation sensor will enable
door opening.
1 Program switch
panel
2 Program switch,
three position
3 Exit only switch,
two position
4 Comm port for
Dorma Handheld
. Program switch panel. Distributor information
.. Knowing act definition
Low energy doors use the term "knowing act".
ANSI/BHMA standard A. definition:
Consciously initiating the powered opening of a low
energy door using acceptable methods including:
• Push plates.
• Fixed non-contact switches.
• Action of manually opening (pushing or pulling)
a door.
• Controlled access devices such as keypads, card
readers, and key switches.
. Knowing act
