dormakaba ED250 IG Owner's Manual Chapter 5
. Low energy power operated
swing doors
.. Performing daily safety checks
Perform safety checks daily on your low energy swing
door to insure your customer and employee safety.
These daily safety checks are also listed in Chapter ,
Safety Information labels, low energy swinging doors.
. Activate the door by a knowing act (Para..).
• Door should open at a slow smooth pace
( seconds or more) and stop without impact.
. Door must remain fully open for a minimum of
seconds before beginning to close.
• Door should close at a slow smooth pace
( seconds or more) and stop without impact.
. Inspect the floor area, it should be kept clean with no
loose parts that might cause user to trip or fall. Keep
traffic path clear.
. Inspect door's overall condition. The appropriate
signage (Chapter ) should be present and all
hardware should be in good condition.
. Have door inspected by a dormakaba USA Inc.
AAADM certified technician at least annually.
WARNING
If there are any problems, discontinue door
operation immediately and secure the door in
a safe manner.
Call your local dormakaba USA Inc. distributor
for repair.
Fig. 5.1.4 Two way traffic, overhead mounted presence
sensor
Fig. 5.1.3 Two way traffic, door mounted presence
sensors
Minimum
activating
detection
zone
43”
[1092 mm]
Minimum
activating
detection
zone
Safety
detection
zone
Guide
rail
Open door plus
55” [1397 mm]
minimum guide rail
and activation zone
length
Open door plus
55” [1397 mm]
minimum guide rail
and activation zone
length
Minimum
activation
detection
zone
Guide rail
Minimum
activation
detection
zone
43”
[1092 mm]
5” max.
5” max.
Safety zone
Safety zone
