Dormakaba Saffire LX Installation Guide

Page 15 of 28 Saffire LX
• Re-install the face plate with its two screws.
• Install the strike and the dust box on the door frame
Important: When strike is installed on wood frames under one inch
thick, wood screws supplied are not adequate. Use screws of efficient
lenght to engage the structural stud behind the frame. Use only the strike
and dust box supplied. Use of non-approved parts may void the warranty.
8.2. Installing the cylindrical models (if lock equipped)
IMPORTANT
For cylindrical latch models, ensure the dead-locking pin will stop against the
strike when the door is closed (see figure). An incorrect installation that permits

Dormakaba Saffire LX Specifications

General

Brand	Dormakaba
Model	Saffire LX
Protection Class	IP54
Access Method	RFID
Power Source	Battery
Operating Temperature	-30°C to 60°C (-4°F to 140°F)
Material	Stainless Steel
