Dormakaba SVA 2000 - 1 Information about this Document; Contents and Purpose; Target Group; Other Applicable Documents

1 Information about this
document
1.1 Contents and purpose
SVA door locks are mounted on the active leaf of a
2-leaf unit. The locks are available in various designs
for tubular frame doors and solid doors. This manual
describes how to mount an SVA lock.
1.2 Target group
SVA door locks must only be mounted by technically
qualified personnel.
1.3 Other applicable documents
• Manual for the connection cable SVP-A1100/2100
(not necessary for SVA5000)
• Mounting instructions for the SVI lock on the fixed
leaf
• Mounting instructions for the components used, e.g.
the door handle
1.4 Abbreviations
SVA
Active, self-locking
(anti-)panic lock for the
active door on 2-leaf
door units
SVI
Inactive, self-locking
(anti-)panic lock for the
fixed door on 2-leaf
door units
2000, 2000F,
4000, 5000,
6000
All versions of a door lock; the
exact lock type is marked with 3
digits instead of zeros.
TMS Soft®
Software for the dormakaba
door management system (TMS)
DCW® bus
DCW® is short for "DORMA
Connect & Work".
A dormakaba-owned fieldbus
system for the connection of up
to 4identical components to a
DCW® central unit.
CAN bus
Serial fieldbus system according
to ISO11898-3, for connecting
several components to one cable
harness
RR Tubular frame locks
VB Solid door locks
G Active leaf
S Fixed leaf
1.5 Symbols used
1.5.1 Hazard categories
WARNING
This signal word indicates a possible
hazardous situation which may result in
death or serious injury if not averted.
TIPS AND RECOMMENDATIONS
This signal word indicates useful information
for efficient and trouble-free operation.
1.5.2 More symbols
1. 2.
Sequence of action steps
1
2
Item numbers used in image
caption
2
SVA door locks
2019-07
WN 059743 45532
dormakaba Mounting instructions Information about this document
