Dormakaba TS93 Series User Manual

dormakaba TS93 GSR/EMF T 1A, 1I, 2 Installation Instructions
08280031 08-2019TS93 GSR Surface Applied Closers
11
Adjust spring force
Secure covers
. Adjust spring force
Increase
Decrease
TS9315
NOTE: Supplied with a size 2 spring setting.
Barrier free openings: Take an opening force reading from the
pull on the door. If required, adjust the spring force to meet the
barrier-free requirement.
• Decrease force: turn counter-clockwise
• Increase force: turn clockwise
Depending on opening conditions, a door adjusted to meet
barrier-free forces may not have sufficient power to reliably close
and latch the door.
TS9356
NOTE: Supplied with a size 6 spring setting.
• Increase force: turn clockwise  times (max)
Regular Mount, Pull side closers
Closer size
Max door
weight (lbs)
Door width
Full turns
Interior Exterior
TS
  '" --- +
  ' '" +
  '" ' +
  ' '" +
TS
  ' '" -
  '" ' 
4 Install covers
.. Snap both end covers onto closer body end caps.
.. Remove un-needed tab, and snap cover over closer body.
.. Secure with one - Phillips pan head screw.
.. Center cover: Measure distance between track covers,
and subtract /”. [X - 1/2” = center cover length]
.. Cut center cover to length measured, and slide over
coordinator system.
.. Snap center caps on to track.
Tab
- pan
head screw
Closer cover
End caps
Center
caps
Center
cover
Track
cover
Track
cover
X

Dormakaba TS93 Series Specifications

General

Category	Door Opening System
Mounting	Surface Mounted
Backcheck	Adjustable
Closing Speed	Adjustable
Latching Action	Adjustable
Body Material	Aluminum
Type	Cam Action Door Closer
Hold-open	Optional
Certifications	EN 1154
Door Weight	Up to 120 kg
Finish	Silver
