dormakaba TS93 GSR/EMF T 1A, 1I, 2 Installation Instructions
08280031 08-2019TS93 GSR Surface Applied Closers
6
Installing slide channel
Installing main arm
. Installing the main arm
Fig.
NOTE: EXAMPLE: Left hand active door shown. For
right hand active installations, install active track
assembly on right hand door and inactive track
assembly on left hand door.
.. Orient track with coordinator toward center of
doorway.
.. Secure track to door frame via holes closest to
center of door first.
• Use two -x” FH screws with a Phillips flat
head driver.
.. Insert end caps into track.
.. Secure end of track through end caps.
• Use two -x” FH screws.
.. Slide end cap covers onto end caps.
. Installing the slide channel
Fig.
.. Attach /” wrench to bottom pinion.
.. While looking up, rotate pinion (square) until it aligns to
square hole on arm.
LH = turn ° counter-clockwise
RH = turn ° clockwise
Right hand door
(Inactive)
Left hand door
(Active)
Right hand door
-x" FH
End cap
covers
End caps
-x" FH
Coordinator towards
center of doorway
Main arm
Right hand door
(Inactive)
Left hand door
(Active)
Pinion screw
Pinion
Door frame hidden for
better view of arm
attachment.
.. Arm is parallel to door.
.. Secure with Mx socket head fastener.
• Use an M hex key.
