Dormakaba TS93 Series User Manual

dormakaba TS93 GSR/EMF T 1A, 1I, 2 Installation Instructions
08280031 08-2019TS93 GSR Surface Applied Closers
4
Surface closer system
Handing the door
Fig.
Hinge
Hinge
Exterior side of door
Interior side of door
Left hand door (LH)
Right hand door (RH)
The surface closer is comprised of the following components.
. Closer body: “B” body
. Main arm
. Active track assembly
. Inactive track assembly
. Pinion
. Track covers and center cover
. Closer cover
. Closer end caps
. Connecting channel
. Handing the door
Fig.
. Surface closer system
1
5
78
6
3/4 3/4
6
9
2
2

Dormakaba TS93 Series Specifications

General

Category	Door Opening System
Mounting	Surface Mounted
Backcheck	Adjustable
Closing Speed	Adjustable
Latching Action	Adjustable
Body Material	Aluminum
Type	Cam Action Door Closer
Hold-open	Optional
Certifications	EN 1154
Door Weight	Up to 120 kg
Finish	Silver
