12
1.1 Housing Dimensions (Available Separately)
The dimensions shown are approximate and subject to change without prior notice.
259mm
10.205in
56mm
2.189in
220mm
8.661in
20mm
0.787in
34mm
1.346in
1.2 Dress Plate Dimensions (Available Separately)
260mm
10.236in
58mm
2.283in
