1.1 Technical Data
Materials
Bolt Stainless Steel 17-4PH
Lock / Strike Plate Stainless Steel 304
Mechanical
Bolt Extension 13mm
Door Gap max. 6mm (¼ inch)
Misalignment Correction max. 8mm (5/16 inch)
Cycle Life 1,000,000 cycles
Holding Force 10,000N (2,250 lbf) (factory tested only)
Side Load Release 6,000N (1,350 lbf) (factory tested only)
Locking Time 1.0 seconds (typical)
Unlocking Time 0.3 seconds (typical)
Environmental
Operating Temperature -10°C to +55°C
Electrical
Power Requirements 12-24 VDC ±15%
Initial Power Up Time 11 seconds
Initial Current Draw 750mA@12VDC, 400mA@24VDC
Standby Current 40mA@12VDC, 25mA@24VDC
Signal Contacts Bolt Position (NO)
30VDC max., 100mA max.
Door Position (NO)
Compliance
CE, UKCA, UL, FCC, IC, RCM, RoHS 2
