DORS 800 BANKNOTE SORTERDORS 800 BANKNOTE SORTER
Table 1
Rejection
reason
Description
Teller's actions
Double note:
dark
A double banknote or a very
dark banknote has been
detected.
Remove the banknote. If
required, adjust the feeder
gap («-» means gap
decrease) for operation with
thinner banknotes. To get the
required gap, turn screw 1
(Figure 1) clockwise.
Double note:
transparent
A very transparent banknote
has been detected.
Remove the banknote.
Table 1
Rejection
reason
Description Teller's actions
Dimensions
A banknote has difference
with the average dimensions
of the first five notes in a
batch (the difference is
exceeded 20 mm by the long
side of note or 10% of its short
side).
Remove the banknote. Adjust
the feeder gap (if required)
according to article 3 of
section «Operation».
Skew error
The banknote skew angle
exceeds 14˚.
Adjust the hopper's guides in
accordance with the length of the
longest note in the batch. If
required, adjust the banknote
feeder gap («+» means gap
increase) for operation with thicker
banknotes. To get the required gap,
turn screw 1 (Figure 1)
counterclockwise.
UV Reflection
or/and
UV
Transmission
A banknote with an increased
level of UV luminescence is
found.
Remove the banknote and
recount it. If the high level of
UV luminescence is a feature
of this type of banknotes,
switch off UV-T or/and UV-R.
MG
A banknote with wrong MG
marks is found.
Remove the banknote.
Scanner error
Banknote scanning error. Place the banknote into the
hopper and recount.
Length
Short side of the banknote is
exceeded 120mm (a probable
reason can be: a banknote
has passed with a large skew
or the banknotes got stuck
together).
Remove the banknotes
and recount them. If
required, adjust the feeder
gap.
Couldn't sort
Banknote feed error.
Remove the banknotes and
recount them.
Note quota
overflow
There are more banknotes fed
than required by the current
mode (batch size, stacker
capacity).
Remove the banknotes and
recount them.
7 Key «ADD»
By pressing the «ADD» key, the accumulation mode is switched on or
switch off . The accumulation mode is intended for summing up of the
number of the counted banknotes by denominations and calculation of their
total amount; the new counting result will be added to the number counted
before. To clear the results, press the « RESET» key.
Please pay attention that in the course of a count you see on the screen the
number and the amount of current batch (in MIX and DEN modes) while
when a count is finished you see the total number and total amount of all the
banknotes counted since the start of accumulation mode.
8 Key «AUTO/MAN»
Key «AUTO/MAN» (see Fig. 13) switches the sorter between automatic
start mode and manual start mode .
An automatic start mode means the sorter is started to count automatically
as soon as the banknotes have been placed into the hopper.
A manual start mode means the user have to push or keys
(depending on the selected user profile) to start a count.
9 Key «DETECTION»
Key «DETECTION» provides a fast access to detection modes associated
with a chosen counting mode. In MIX or DEN mode this key calls a pop-up
menu (ahead of a main screen) where you can turn on/off such kinds of
detection as UV-R, MG, STRICT (see Fig. 52). An activated kind of
detection is highlighted by blue color (see Fig. 52), an disactivated one
becomes grey:
