Installation -3
Version 1.36
02/2004
(2) Machines shipped with a fixed water connection (plumbed-in unit).
7. Place chilled coffee pack
8. Rinse the water system
thoroughly
Installation completed
Check water quality / water
pressure requirements:
(min. : 0.8
bar dynamic pressure / max. 10
bar static pressure)
Start
9. Calibrate and program machine
1.Unpack machine.
4
2
2
3
NSF (US)
version
6
5
5
7
*The numbers correspond with the steps of the procedure.
** Size and type of filter may vary depending on local circumstances. Not illustrated here
Additional
labels NSF
version
4. Connect power cord
2. Attach labels / operation panel
cover
3. Place water stop valve,
install water filter**
and connect water supply hose
6. Switch machine on
5. Install drip tray with grille
and trough
