Douwe Egberts Contenta - Inlet Valve

Functions (water) - 10
Version 1.36
02/2004
Overview Water system components - Fixed
water connection
Boiler
Inlet valve
Top view
Boiler
Heater
Overflow
Outlet trough
Outlet trough
Water Coffee
Level sensor
Drain hose
NTC
Temperature
Sensor
Coffee/Water
2x
Overboil
sensor
Water
Coffee
The water system of machines with a fixed water connection does not include the water tank compo-
nents, whereas the location of the inlet valve differs.
