Douwe Egberts Contenta - Testing Machine Components and Functions

Programming -5
Version 1.36
02/2004
Input
1
Testing sub-menu structure
D. Testing sub-menu
Enter the installation sub-menu to test functions and components. You can scroll through the various items
with the up/down keys and activate a machine part or function with the key. The part/function can then be
noticed or the function related in/output voltages can be measured.
Input
TESTING
CONCENTRATE TEST
1= ON FOR 1 SECOND
ALL LED’S
1= ON FOR 1 SECOND
HEATING ELEMENT
1= ON FOR 1 SECOND
PELTIER ELEMENT
1= ON FOR 1 SECOND
COFFEE VALVE
1= ON FOR 1 SECOND
HOT WATER VALVE
1= ON FOR 1 SECOND
WATERINLET VALVE
1= ON FOR 1 SECOND
B2 Coil Dosing test. The dosing pump of the coffee
pack action should be clearly audible.
Place a cup under the coffee outlet and clean the
trough afterwards.
LED test. Verify that every LED is properly
functioning.
Heating element/relay test. When actuated the
relay will produce an audible ‘click’.
Peltier test. Measure the in/output voltages over the
related pins/connectors. (When the Peltier element
is activated, a change of fan operation is audible)
The Peltier element will switch off for 3 seconds
after it has been activated.
Valve test. The rear outlet valve (coffee) should
open for 1 second. Place a cup under the coffee
outlet.
Valve test. The front outlet valve (hot water) should
open for 1 second. Place a cup under the hot water
outlet.
Valve test. The water inlet valve should open for 1
second. When actuated the valve will produce an
audible ‘click’.
It is possible that too much water flows
into the boiler due to repeated inlet valve
testing. This may result in overflowing!
Allow time to reset.
