LMA-A REV.DOC 23/04/08
7
The scraper above the sheeter’s superior cylinder (point A, fig. 3.7) which is fixed to it, can
be removed to clean the machine.
The scrapers of the sheeter’s inferior cylinder (point B, fig. 3.7) are fixed to the lateral parts
of the sheeter, to clean the cylinder and the canvas.
Fig. 3.7
Under each working board, there is a flour collector (fig. 3.8), which can be easily removed
by loosening the lateral screws from the tables (fig. 3.9) and pulling them.
Fig. 3.8 Fig. 3.9
The sheeter LSB516 and LMF624 has two rolling pins, which you can work with.
A
B
