FIELD and BRUSH MOWER Safety & Operating Instructions 31
Adjusting the Blade Engagement Cable
Note: If the blade won't cut, or seems to slip in heavy material, check the blade
engagement cable.
Tool Needed:
■ 1/2" open-end wrench
On the right handlebar there is a black bracket for adjusting the blade engagement cable
(Figure 24). To tighten the cable, turn the center portion of the adjuster counter
clockwise. To loosen the cable, turn the adjuster clockwise.
Figure 24
WARNING! Before performing any maintenance procedure, stop the
engine and disconnect the spark plug wire(s).
Blade Engagement Cable Adjustment
