12 DR
®
SCOUT
™
FIELD and BRUSH MOWER
DR SCOUT FIELD and BRUSH MOWER Controls and Features
NOTE: The model shown in Figure 1 may look slightly different from your machine.
Figure 1
Key Switch
Throttle Control
Operator Presence
Control Lever
Blade Engagement Lever Wheel Clutch Lever
Shift Lever
Recoil Starter Handle
Engine Primer Bulb
