46 DR

SCOUT

™

FIELD and BRUSH MOWER

Parts List - Differential and Wheel Assembly

NOTE: Part numbers listed are available through Country Home Products, Inc.

Ref# Part# Description

01 180171 Differential, 700-268

02 108921 Flange, Ball Bearing, 2-hole

03 152171 Bearing, Ball, 3/4" Bore

04 123211 Bolt, 5/16"-18 x 3/4" HCS

05 110761 Nut, Nylon Lock, 5/16"-18

06 175431 Wheel, 14.5" x 7-6 2ply

07 111481 Bolt, 1/4"-20 x 1-3/4" HCS

08 110731 Nut, Nylon Lock, 1/4"-20

09 180151 Chain, #40, 77 Link w/ML
