DR SCOUT FIELD and BRUSH MOWER User Manual

40 DR
®
SCOUT
™
FIELD and BRUSH MOWER
CHAPTER 7
PARTS LISTS, SCHEMATIC DIAGRAMS AND WARRANTY
Parts List - Handlebar Assembly
NOTE: Part numbers listed are available through Country Home Products, Inc.
Ref# Part# Description
01 165361 Handlebar Assy w/Control Panel
02 120301 Screw, 3/8"-16 x 1-1/2", Tri-Lobe
04 165201 Switch, Snap-In
05 157201 Key, AT2 Ignition Switch
06 139051 Cable, Throttle, 50"
07 150491 Screw, 8-32 x 1/2"
08 165171 Lever, Wheel Clutch, 1"
09 164951 Grip, Handlebar, Ergonomic, 1"
10 164971 Guard, Switch
11 175381 Cable, Traction Drive,
12 180951 Lever, Blade Engage, w/ Switch
and Harness Adapter
13 164961 Grip, Handlebar, Plain, 1"
14 178991 Cable, Blade Engage
15 109161 Bolt, Eye
16 110691 Nut, 5/16"-18
17 110761 Nut, Nylon Lock, 5/16"-18
18 179231 Screw, M6 x 25mm
19 181731 Operator Presence, w/Switch and
Harness adapter
Items Not Illustrated
180941 Wire Harness, B&S
112141 Cable Tie, 7-1/2", black
Safety and Information Labels
225851 Label, Control Panel
173351 Label, Gear Shift
179251 Label, Shift Lever
124371 Label, American Flag
127811 Label, Warning, Add Oil
136491 Label, Danger
136831 Label, Caution Hot Surface
137581 Label, Check Oil
148231 Label, Safety Icons
211651 Label, Throttle
211641 Label, Warning
