Dräger Aerotest HP User Manual

36
Aerotest Alpha Aerotest Navy MultiTest med. Int.
Carrying case
Length x width x height (mm) 350 x 300 x 85 400 x 300 x 91 400 x 300 x 91
Colour black blue blue
Weight, with contents approx. 3 kg approx. 3 kg approx. 3 kg
Pressure reducer
Input Plug-in nipple External thread G5/8-300
bars (manual connection)
G1/8
Maximum primary pressure 15 bars 300 bars 15 bars
Pressure gauge 0.3 to 15 bars 0 to 400 bars 0.3 to 15 bars
Output 9 mm plug-in coupling for
measuring device
9 mm plug-in coupling for
measuring device
9 mm plug-in coupling for
measuring device
Relieve valve Without Set to 10
+2
bars Without
Adapter 1
Input 9 mm plug-in coupling Internal thread
830-14NGO-RH-INT
Without
Output External thread G1/4 Internal thread G5/8-300
bars for pressure reducer
Without
Adapter 2
Input Internal thread External thread
825-14NGO-RH-EXT
Without
Output 12 mm plug-in nipple Internal thread G5/8-300
bars for pressure reducer
Without
Ambient conditions 15 °C to 25 °C, 1013 mbars 15 °C to 25 °C, 1013 mbars 15 °C to 25 °C, 1013 mbars
Measurement device
Length x width (mm) 100 x 38 100 x 38 160 x 38
Height, including Dräger
tube holder (mm)
230 230 230
Connection for
compressed gas supply
Plug-in nipple 9 mm Plug-in nipple 9 mm Plug-in nipple 9 mm
Primary pressure Set at delivery 3.0 bars 8.5 bars 3.0 bars
Volume flow
CO and CO
2
tubes 0.2 l/min 0.2 l/min 0.2 l/min
Impactor, oil tubes and
H
2
O tubes
4 l/min 4 l/min
Oil PN tubes 0.2 l/min
Nitrous gas tubes, H
2
S and
SO
2
tubes
0.2 l/min
O
2
tubes 1 Hub
