Technical data
Aerotest HP Aerotest HP USA Aerotest HP NF Aerotest NOx
Carrying case
Length x width x height (mm) 350 x 300 x 85 350 x 300 x 85 350 x 300 x 85 350 x 300 x 85
Colour black black black black
Weight, with contents approx. 3 kg approx. 3 kg approx. 3 kg approx. 3 kg
Pressure
reducer
Input External thread G5/8-300
bars (manual connection)
External thread G5/8-
300 bars (manual
connection)
External thread M25x2
300 bars (manual
connection)
External thread
G5/8-300 bars
(manual connect.)
Maximum primary pressure 300 bars 300 bars 300 bars 300 bars
Pressure gauge 0 to 400 bars 0 to 400 bars 0 to 400 bars 0 to 400 bars
Output 9 mm plug-in coupling for
measuring device
9 mm plug-in coupling
for measuring device
9 mm plug-in coupling
for measuring device
9 mm plug-in
coupling for
measuring device
Relieve valve Set to 10
+2
bars Set to 10
+2
bars Set to 10
+2
bars Set to 10
+2
bars
Adapter 1
Input Internal thread G5/8-200
bars
Internal thread
830-14NGO-RH-INT
Without Internal thread
G5/8-200 bars
Output Internal thread G5/8-300
bars for pressure reducer
Internal thread G5/8-
300 bars for pressure
reducer
Without Internal thread
G5/8-300 bars for
pressure reducer
Adapter 2
Input Internal thread G5/8-200
bars
External thread
825-14NGO-RH-EXT
Without Internal thread
G5/8-200 bars
Output Internal thread G5/8-300
bars for pressure reducer
Internal thread G5/8-
300 bars for pressure
reducer
Without Internal thread
G5/8-300 bars for
pressure reducer
Ambient
conditions
15 °C to 25 °C,
1013 mbars
15 °C to 25 °C,
1013 mbars
15 °C to 25 °C,
1013 mbars
15 °C to 25 °C,
1013 mbars
Measurement
device
Length x width (mm) 100 x 38 100 x 38 100 x 38 120 x 38
Height, including Dräger
tube holder (mm)
230 230 230 230
Connection for
compressed
gas supply
Plug-in nipple 9 mm Plug-in nipple 9 mm Plug-in nipple 9 mm Plug-in nipple
9mm
Primary
pressure
Set at delivery 8.5 bars 8.5 bars 8.5 bars 8.5 bars
Volume flow
CO and CO
2
tubes 0.2 l/min 0.2 l/min 0.2 l/min 0.2 l/min
Impactor, oil tubes and
H
2
O tubes
4 l/min 4 l/min 4 l/min 4 l/min
Nitrous gas tubes 0.2 l/min
