9.2 Attachment 2: Overview of Ventilation Modes
Overview of Ventilation Modes in Critical Care Ventilators and Terms Used in Different Dräger
Anesthesia Devices
Possibly your device does not dispose of all described modes – sometimes they are not ordered in the
device configuration.
Fabius Family:
Mode name ICU ventilator
Mode key name Fabius
VC-CMV
Volume Control
PC-CMV
Pressure Control
VC-SIMV/PS
SIMV/PS
SPN-CPAP/PS
Pressure Support*
Not available
Man / Spon
Apollo Family:
Mode name ICU ventilator
Mode key name Apollo
Mode name on screen Apollo
VC-CMV
Vol. mode
Volume
VC-SIMV
(Activate Trigger parameter)
Volume Sync
VC-SIMV/PS
(Activate ∆Pps parameter)
Volume Sync PressSupp
VC-CMV AutoFlow
Vol. AF mode
Volume AF
VC-SIMV AutoFlow
(Activate Trigger parameter)
Volume AF Sync
VC-SIMV/PS AutoFlow
(Activate ∆Pps parameter)
Volume AF Sync PressSupp
PC-CMV
Press. mode
Pressure
PC-SIMV
(Activate Trigger parameter)
Pressure Sync
PC-SIMV/PS
(Activate ∆Pps parameter)
Pressure Sync PressSupp
SPN-CPAP/PS
Press. Supp.
Press. Support*
SPN-CPAP
Press. Supp.
Press. Support CPAP
Not available
Man / Spon
Man. Spont.
Not available
Symbol (Semi-open circuit)
Ext. Outlet
Not available
Monitor. mode (Standby screen: Soft Key)
Monitoring
*(Apnea Ventilation available with setting FreqMIN)

Dräger Fabius Series Specifications

General

Type	Anesthesia Workstation
Manufacturer	Dräger
Ventilation Modes	SIMV
Flow Control	Electronic
Tidal Volume Range	20 to 1400 mL (model dependent)
Respiratory Rate	4 to 60 breaths/min
PEEP	0-20 cmH2O
Gas Supply	O2, Air, N2O
Vaporizer Mounts	2
Monitoring	O2, CO2, N2O
Dimensions	Varies by model
Weight	Varies by model
Model	Fabius Series
Category	Anesthesia
