Dräger Flame 1500

16 Instructions for use | Flame 1500
en | Technical data
10 Order list
Terminal wire size:
2.5 mm
2
(14 AWG)
Ingress protection: IP66 (NEMA 4X)
Mounting bracket
Support fixing: M8 (quantity 2)
Vertical adjustment range: 0 - 45°
Horizontal adjustment range: ±45°
Environmental specification
Operation ambient temperature: -60 to +85 °C (-76 to +185 °F)
Storage ambient temperature: -60 to +85 °C (-76 to +185 °F)
Relative humidity: 0-100 % (non-condensing)
Operation specification
Detector range (depth of field): 2-60 m (6-200 ft)
Sensitivity range: Low, Medium (Factory default) and
High
Detector response time: 4 - 30 s
Horizontal field of view: 90°
Vertical field of view: 90°
Alarm setting: Non-latching with automatic reset
after 15 s (default) OR Latched until
the power is removed from detector.
Self-test facility: Yes – no mirror continuous automatic
optical verification
Heated optics Yes
LED status Tri-state LED
Output options:
0(4) - 20 mA, HART
®
7, Relay con-
tacts - alarm and fault
Relay: 2 Relay Contacts – Alarm and Fault.
DPDT, 2 A @ 30 Vdc
Communication/Configuration:
RS485 and HART
®
7
RFI/EMC: Complies with IEC 61000
Power on reset delay: 5 s
Description Part number
Dräger Flame 1500 variants
2 x M25, aluminium 372 15 19
2 x M25, stainless steel 372 15 18
2 x 3/4” NPT, aluminium 372 15 17
2 x 3/4” NPT, stainless steel 372 15 16
Flame simulator
Dräger FS-5000 42 093 07
Accessories
Bracket standard, 316 stainless steel 37 18 732
Bracket marine, 316 stainless steel 37 01 298
Sunshield, Flame 1x00/3x00/5x00 37 01 299
Mount kit, 2" pole 37 01 300
Mount kit, 3" pole 37 01 301
Mount kit, 4" pole 37 01 302
Sealing kit detector, metric 37 01 303
