Dräger Flame 1500

8 Instructions for use | Flame 1500
en | Description
WARNING
Explosion hazard!
A damaged flame path could lead to an explosion. Opening the flame detector
in an explosive atmosphere may cause an explosion.
► Do not open the flame detector in presence of an explosive atmosphere.
► Ensure that the flame path of the flame detector is not damaged during
installation.
CAUTION
Risk of damage to the device!
Incorrect disassembly of the flame detector may damage the device.
► Only appropriately trained service personnel may open the enclosure.
2.2.5 Status indicator
The status of the flame detector is indicated by the colour of a status LED
located below the lens:
2.3 Intended use
The flame detector is designed for use in areas that may contain a potentially
explosive atmosphere (see "Approvals", page 8).
It is used to monitor an area and trigger the necessary control actions upon the
detection of fire or flame within its field of view.
2.4 Limitations on use
– The flame detector is not approved for use in oxygen-enriched
atmospheres.
– As the flame detector responds to flame, it cannot be used in locations
where flare stacks and other open flames are within its field of view without
triggering false alarms.
– The flame detector responds to CO
2 emissions of a flame; therefore, it
cannot detect non-hydrocarbon fires such as those using pure hydrogen,
and sulphur as fuel.
– The flame detector may be obscured by extremely dense fog, smoke or
other airborne particulates.
– Arc welding should not take place within 10 m of the flame detector when
using the highest sensitivity setting.
2.5 Approvals
For information - certificate numbers may change.
LED Status
Steady OFF No power/Major internal fault
Steady Green Healthy
Flashing Green 24 V/0 Vdc polarity reversed
Steady Yellow Fault
Red Alarm
One yellow flash at start up Set to low sensitivity (15 m)
Two yellow flashes at start up Set to standard sensitivity (30 m)
Three yellow flashes at start up Set to high sensitivity (60 m)
Parameter
Authority/
Standard
Approval Certificate
Hazardous area certifica-
tion
ATEX II 2 G Ex db IIC T4 Gb FM21ATEX0012X
Hazardous area certifica-
tion
NEC 505
Class 1,
Zone 1 AEx db IIC T4 Type
4X
Hazardous area certifica-
tion
NEC 500
Class 1, Div. 1, Groups B,
C, D T4 Type 4X
Hazardous area certifica-
tion
IECEx Ex db IIC T4 Gb
IECEx FMG
21.0009X
American fire service list-
ing
FM Class 3260, 3615, 3600
Certified SIL 2 Capable Exida Certified SIL 2 Capable DR 21-01-151 C001
