INFINITY CENTRAL STATION & M300 QUICK REFERENCE GUIDE
| 21
THIS GUIDE IS INTENDED
FOR REFERENCE
ONLY. REFER
TO
INSTRUCTIONS FOR USE
MANUAL.ADDITIONAL INFORMATION
TO SELECT A DIFFERENT WAVEFORM FOR VIEWING ON THE ICS
(BEDSIDE MONITORS ONLY)
1. Right-click with the mouse inside the waveform area of the
patient while on the Mainscreen.
2. Select Auto to maintain the display order selected at the bed-
side.
OR
3. Select Manual to assign up to four waveforms to the waveform
areas. Select the arrow and choose the desired waveform or-
der.
4. Select the Apply button to confirm the new waveform selec-
tion. The following symbol appears in the header bar of the
Viewport in Manual mode:
TO CHANGE THE COLOR OF THE M300 PATIENT WAVEFORMS &
PARAMETER VALUES AT THE ICS
1. Open the BedView page by selecting the viewport of the te-
lemetry patient on the ICS Main screen.
2. Select Telemetry/Parameters button on the Bedview menu
bar.
3. Select the Layout/Parameters tab.
4. Select the ECG tab.
5. Use the arrow to select the desired color. Select Apply.
6. Select SpO
2
tab.
7. Use the arrow to select the desired color. Select Apply.
Note: For a bedside monitored patient, this must be completed at
the bedside monitor.
TO INITIATE A MANUAL RECORDING (R50N, if available)
1. Left-click the mouse in the waveform area of the patient’s
Main screen viewport to display the Record button symbol
(appears for 5 seconds):
