ECG Menu Options
TO SELECT ARRYTHMIA LEADS FOR PROCESSING AND ADJUST
SCALE FOR AN M300 PATIENT
1. Open the BedView page by selecting the viewport of the te-
lemetry patient on the ICS Main screen.
2. Select the Telemetry/Parameters.... button on the Bedview
menu bar.
3. Select the Layout/Parameters tab.
4. Select the Layout tab.
5. Select the arrow of appropriate channel and choose desired
lead for QRS/ARR processing in channel 1 or 2 in the Wave-
form column.
6. Select the Gain/Scale arrow to increase or decrease the wave-
form size.
7. Select the Apply button.
TO SELECT PACER DETECTION FOR AN M300 PATIENT
1. Open the BedView page by selecting the viewport of the te-
lemetry patient in the ICS Main screen.
2. Select the Telemetry/Parameters.... button on the Bedview
menu bar.
3. Select the Layout/Parameters tab.
4. Select the ECG tab.
5. Select Pacer Detection On/Off as appropriate. Select Fusion if
available and clinically appropriate.
6. Select Apply.
TO CHECK LEAD PREP, BATTERY STRENGTH & SIGNAL STRENGTH
FOR AN M300 PATIENT
1. Open the BedView page by selecting the viewport of the te-
lemetry patient on the ICS Main screen.
2. Select the Telemetry/Parameters.... button on the Bedview
menu bar.
