Dräger Infinity Central Station - Data Transfer and Troubleshooting; Data Transfer Procedures

© 2014 Draeger Medic al , Inc .
INFINITY CENTRAL STATION & M300 QUICK REFERENCE GUIDE
| 31
THIS GUIDE IS INTENDED FOR REFERENCE ONLY. REFER TO INSTRUCTIONS FOR USE MANUAL.ADDITIONAL INFORMATION
Transfer of Data
Note: Only trend and demographic data will transfer. Units of measure for
both devices must match. Some devices/software levels do not fully support
electronic data transfer. Only patients in Standby mode are candidates for
transfer. Refer to individual device IFU’s.
TRANSFER M300 TO M300
1. Place the M300 (containing the data to be transferred)
in
Standby mode .
2.
Proceed to the parameter bo x of the admitted M300 y ou want to
transfer the data to.
3. Select the
A dmit/S tandb y ... button on the Bed-View menu bar.
4. Select the
Data Transfer tab.
5. Select the
arrow button next to the Care unit field to select the
desired care unit in which the M300 is located. A list of patients
in the selected care unit appears.
6. Select the
desired patient from the selection list.
7. Select the
Start transfer button. A c onfir ma t ion pop-up window
appears.
8. Select Yes in the confirmation popup to start the data transfer.
The message Transfer completed appears after the data have
been transferred.
TRANSFER DRÄGER BEDSIDE MONITOR TO M300
1. Place the source bedside monitor in Standby mode.
2. Select admitted M300
parameter bo x at the ICS to open BedView
page.
3. Select the
A dmit/S tandb y ... button on the BedView menu bar.
4. Select the
Data Transfer tab to access the Transfer page.
5. Select the
arrow button next to the Care unit field to select the
desired care unit in which the bedside monitor is located. A list
of
patients in the selected care unit appears.
6. Select the
desired patient from the selection list.
7. Select the
Start transfer button. A confirmation pop-up window
