Operating concept
78 Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n
CO
2 Scale
RRc apnea time [s]
RRc apnea archive
Color
Airway adapter
Averaging
Alarm on/off setting
Alarm limits
Alarm archive setting
Scio CO
2 CO2 parameter field
configuration
Alarm status
Alarm limits
Alarm archive settings
Apnea settings
Waveform scales
Trend scales
CO
2 color
Scio O
2 O2 parameter field
configuration
O
2 mini trend configuration
Alarm status
Alarm limits
Alarm archive settings
Waveform scales
Trend scales
Parameter Included settings
Scio Agent
(see page 365)
Agent selection (for variants
with manual identification
only)
Agent parameter field
configuration
Agent/xMAC mini trend
configuration
Alarm status
Alarm limits
Alarm archive settings
Trend scales
Trends Graphical trend setup
Tabular trend setup
Reports Case summary setup
External device profile settings
External devices –
CCO/SvO2
(see page 398)
Parameter 1
Parameter 2
Parameter 3
Mini trends
External devices –
Paw
(see page 439)
Parameter 1 (paw)
Parameter 2 (paw)
Parameter 3 (paw)
Paw scale
Vol scale
Color
External devices –
ventilator (Medibus
- Servo I)
(see page 440)
Parameter 1 (vent, paw)
Parameter 2 (vent, paw)
Parameter 3 (vent, paw)
Paw scale
Flow scale
CO
2 Scale
Vol scale
Color (vent, paw, CO2)
Parameter Included settings
